Chapter 4. Configuration and Operation
118
The DM command is also used to display the map matrix DS0 Assignment Map. At the Display Map
Number prompt, enter the number of the desired map. In the example below, map 2 has been selected.
At the Display prompt, enter 2 to display the DS0 Assignment Map. (Figure 4-16 shows the entire
prompt sequence after DM.)
The DS0 Assignment Map does not allow strobe assignments to the line cards. Rather, it is used to
assign signaling type or blocking. If no cards are assigned to a DS0, as shown in [Map 2: T1-2], nothing
will be shown in the card slot row display, and Xs should appear on the data line.
] DM
Display Map Number
[2]
Display
1) Linecard Map
2) DS0 Assignment Map
[1] 2
10:31:46-------------------- [ Map 2 : T1-1 ]---------------------- 08/18/92
DS0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
-----------------------------------------------------------------------------
Voice TR TR TR TR TR TR
Data TR x x x x x x x x x x x x x x x x x x x x x
-----------------------------------------------------------------------------
Slot 15 15 18 20 20 22 22
A B A B A B
10:31:50-------------------- [ Map 2 : T1-2 ]---------------------- 08/18/92
DS0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
-----------------------------------------------------------------------------
Voice
Data x x x x x x x x x x x x x x x x x x x x x x x x
-----------------------------------------------------------------------------
Slot
Figure 4-16. Displaying the DSO Assignment Map Prompt Sequence
