Coastcom D/I Mux III System User Manual

Chapter 4. Configuration and Operation
147
Line Card Slot Number
(1A..24D)
[Quit] 1A
Card Type :SDCU
Card Model number :30351-105
DS0:
SLOT 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
---------------------------------------------------------------------------
1A
---------------------------------------------------------------------------
DS0 Range
(1-24)
*) All DS0s
C) Clear All DS0s
[Quit Slot] 1
Enter
T) Transmit
R) Receive
B) Both
C) Clear
[Quit DS0] B
Application
D) Data
V) Voice
[D] V
DS0:
SLOT 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
---------------------------------------------------------------------------
1A TR
---------------------------------------------------------------------------
Line Card Slot Number
(1A..24B)
[Quit] 2
Card Type : SDCU
DS0:
SLOT 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
---------------------------------------------------------------------------
2
--------------------------------------------------------------------------
DS0 Range
(1-24)
*) All DS0s
C) Clear All DS0s
[Quit Slot] 2
Enter
T) Transmit
R) Receive
B) Both
C) Clear
[Quit DS0] B
DS0:
SLOT 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
---------------------------------------------------------------------------
2 TR
---------------------------------------------------------------------------
Line Card Slot Number
(1A..24B)
[Quit] Q
Figure 4-56. Editing a Line Card Slot
