Chapter 5: System operation
184 Use the SBU web interface
Access the AVIATOR 700 from a remote location
To access the SBU from a remote location, do as follows:
1. On the remote computer, open a web browser.
2. Enter the IP address of the SBU followed by colon and the port number
http://<ip address>:<incoming port>.
• <ip address> is the address from step 3 above.
• <incoming port> is the port that has been defined during system
installation.
Example: If the IP address of the SBU is 161.30.180.12 and the
incoming port number defined in the Remote management
page in the web interface is 8080, enter
http://161.30.180.12:8080.
You are now connected to the SBU from the remote computer.
Contact your installation center for further information on the
SBU IP address and port number. Your system may have a
static IP address that is assigned each time when the SBU logs
on.
