9-18 Troubleshooting
2. Insert the bottom leg of the media guide in both sides of the
imager, as shown in the following figure.
3. Rotate the top leg into place, as shown below.
CAUTION
Be careful not to scratch the polished sheet metal or damage the sensor
near the upper guide notch.
Do not damage sensor
