Horizon Start Manual 7-7
Preventive Maintenance
Some Horizon users may prefer to use the Horizon Cleaning
Cassette to clean the pick tires, rather than using the platen roler
cleaning wipe. The Horizon Cleaning Cassette, part number SP-
00279, can be ordered by contacting your Codonics
representative.
1. Press the imager’s key, and wait until the imager enters the
Paused state.
2. Remove the receive trays, as shown in the following figure.
Cleaning the Pick Tires
WARNING With the receive trays removed, touch only those internal
components that are colored green (except for the pick tires, refer to the figure
on page xx). Remove rings, ties, jewelry, and other items, and tie back hair, so
that they do not fall into or get caught in the imager.
PAUSE
14"
x
1
7"
A
S
iz
e
8"
x
10"
Receive trays
To Next Page
