Do not place any liquid containers on the imager. If, for some
reason, liquid seeps into the imager, power off the imager and
unplug the power cord from the source outlet. If used without
corrective measures, the imager may be damaged.
•
Do not use the imager near flammable gases.
•
With the imager top cover open or the receive trays removed,
touch only those internal components that are colored green
(except for the pick tires).
Remove rings, ties, jewelry, and other
items, and tie back hair, so that they do not fall into or get caught
in the imager.
Internal Components That Are Colored Green (called out in the
illustration) Are Safe to Touch (except for the pick tires)
Top cover releases
Spool wheels
Diverter
Upper fender releases
(down position)
Top cover
master release
Media
guides
Picker
(lift here)
Spring-loaded
spindles
Upper fender
releases
(up position)
Pick Tires
(DO NOT TOUCH except with
Platen Roller Cleaning Wipe)
