7-2 Preventive Maintenance
Horizon Cleaning Kits
The following cleaning kit is available to help you properly maintain
the Horizon imager:
•
The Horizon Cleaning Kit (catalog no. SP-00130) includes special
wipes that you will need to clean the thermal print head, platen
roller, pick tires, and other internal components.
Some Horizon users may prefer to use the Horizon Cleaning
Cassette to clean the pick tires, rather than using the platen
roller cleaning wipe. The Horizon Cleaning Cassette, part
number SP-00279, can be ordered by contacting your Codonics
representative.
To order additional cleaning kits, contact Codonics at:
Phone: +1.440.243.1198
Toll Free: 800-444-1198 (USA Only)
Fax: +1.440.243.1334
Web: www.codonics.com
Clean the barcode reader
window
Every 12 months.
Horizon User’s
Manual
Clean the cassette area, sheet
exit area, receive trays,
basement, and imager cabinet
with a platen roller wipe (refer
to “Horizon Cleaning Kits”
below)
Every 2000 sheets to eliminate dust buildup and
prevent dirt from getting inside the imager.
Horizon User’s
Manual
Film calibration This calibration is done automatically whenever a
new cassette is inserted for the first time. You can
also run this calibration manually at any time (for
example, if it has been more than three months since
the cassette was calibrated).
page 8-1
Table 7-1. Recommended Maintenance Schedule (cont.)
Maintenance Schedule Procedure on
