InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
value and input pulses counter are stored in the nonvolatile memory.
The PulseCounter modules are intended e.g. for connecting external energy
or fuel meters with pulse outputs.
NOTE:
Minimal pulse width as well as minimal pause between two succesive pulses
is 100ms.
NOTE:
The counter value can be reset in the InteliMonitor statistics window.
14.2.1.31 Binary input: Timer block 1
This input is used to disable temporarily the output from the Timer channel
#1.
NOTE:
See also the setpoint TimerChannel 1 and output TimerAct 1-4.
NOTE:
See the chapter Timers for more details about timers.
14.2.1.32 Binary input: Timer block 2
This input is used to disable temporarily the output from the Timer channel
#2.
NOTE:
See also the setpoint TimerChannel 2 and output TimerAct 1-4.
NOTE:
See the chapter Timers for more details about timers.
14.2.1.33 Binary input: Timer block 3
