InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
14.2.1.79 Binary input: ForceValueIn16
This input activates the Force value #16 block. If the input is active, the value
of the setpoint, to which the Force value #16 block is configured, will be
overriden by value of the alternative setpoint assigned to the Force value #16
block.
NOTE:
If there are more than one force value blocks configured onto one setpoint
then the highest priority has the block with the lowest index (i.e. the first
active block according to the list displayed in GenConfig in the Force value
window at the related setpoint).
NOTE:
Watch a training video about force value function here:
http://www.comap.cz/support/training/training-videos/.
NOTE:
See an example in the description of the binary input Force value 1.
14.2.1.80 Binary input: Force block 1
This is one of three binary inputs used for user-defined blocking of
protections. If the input is active, all the protections that have Protection block
type configured as Force block 1 block type are blocked (i.e. temporarily
disabled).
14.2.1.81 Binary input: Force block 2
This is one of three binary inputs used for user-defined blocking of
protections. If the input is active, all the protections that have Protection block
type configured as Force block 2 block type are blocked (i.e. temporarily
disabled).
14.2.1.82 Binary input: Force block 3
This is one of three binary inputs used for user-defined blocking of
protections. If the input is active, all the protections that have Protection block
