InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
type configured as Force block 3 block type are blocked (i.e. temporarily
disabled).
14.2.1.83 Binary input: Lang sel int A
This is one of three binary inputs Lang sel int A, Lang sel int B, Lang sel int
C, used for selecting language of the built-in IG-NT terminal (display). As the
IS-NT does not have built-in terminal, this input is assigned to the terminal
(display) #1, which is supposed to be directly attached to the controller or
mounted close to it.
NOTE:
Using these inputs for language selection is an option only. If the inputs are
not configured, the language can be selected using the menus on the
terminal.
ENCODING TABLE
NOTE:
"0" in the table means the input is not active or not configured.
NOTE:
Language index 0 selects the default language of the terminal, i.e. the
language, which is adjusted in the terminal using it's menus.
