InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
15.2.1.21 Binary output: Common Wrn
The output is closed while there is at least one alarm of the Warning type
present in the alarm list. The alarm can be in any state, i.e. active
unconfirmed, active confirmed or inactive unconfirmed. See the chapter
Alarm management for more information.
15.2.1.22 Binary output: Common Fls
The output is closed while there is at least one alarm of the Sensor fail type
present in the alarm list. The alarm can be in any state, i.e. active
unconfirmed, active confirmed or inactive unconfirmed.See the chapter Alarm
management for more information.
15.2.1.23 Binary output: Common BOp
This output closes if any "Breaker Open" type alarm appears. The output
opens if no BO type alarm is active (pressing of fault reset button is not
required).
15.2.1.24 Binary output: Common BOR
This output closes if any "Breaker Open with fault reset" type alarm appears.
The output opens if no BOR type alarm is active (pressing of fault reset
button is required).
15.2.1.25 Binary output: Common Al
The output is closed while there is at least one alarm of the Alarm only type
present in the alarm list. The alarm can be in any state, i.e. active
unconfirmed, active confirmed or inactive unconfirmed. See the chapter
Alarm management for more information.
