ComAp InteliDrive Lite - Analog RPM Control Configuration; Analog RPM Control Details

ID–Lite-2.0 User guide, ©ComAp – January 2011 22
ID-Lite-2.0 User guide.pdf
AOUT
OutChar
Input J1939 – Actual Load in %
Binary input: L Request 2 (optional)
Binary input: Reg Disable (optional)
Output Analog output: Speed request
Setpoints
Load limit: Load Input = Load
Load Bias = 5000
Load Request = 80
Load Request 2 = 100
Load ReqRamp = 80
Load UpLimit = 9000
Load DnLimit = 1000
Load Gain = 50
Load Integral = 80
Load Ramp = 5000
