Statistic
Run hours
Number of starts
E-Stop Number of engine Emergency stops (without Shut-downs)
ShutDown Number of engine Shut down stops (without Emergency stops)
NextServTime
Hint:
Invisible in ID-Lite-s-2.0.ail configuration file.
Running time is measured in complete minutes, displayed in complete hours. Values are stored in
nonvolatile memory.
ECU AlarmList
Diagnostic messages are read from ECU and displayed in this second alarm list. For Standard J1939
engines SPN (Suspect Parameter Number), FMI (Failure Mode Identifier) and OC (Occurrence
Counter) are shown together with verbal description if available.
Following image shows displaying of ECU alarms in the second alarm list. The additional information
for the row selected by cursor is on the last row (SPN, OC and FMI codes).
If the verbal description of alarm is not available, the SPN (decimal and hexadecimal) is displayed.
EngOilPress WRN
BoostPress FLS
EngOilTemp FLS
629(275h) FLS
Controller#1
EngCoolTemp WRN
_____________________
SPN:110 OC:7 FMI:3
Hint:
For FMI = 0 and 1, WRN is displayed. For other FMI codes, FLS is displayed.
Alarm list
Displays active or inactive alarms configured on ID-Lite Binary or analog outputs.
ID-Lite controller automatically switches to the Alarm list screen when any new Alarm appears, but
from Main measure screen only.
