InteliLite Global Guide
100
Cooling Cooling Time (page 219) elapsed FUEL SOLENOID (PAGE 602) off,
STOP SOLENOID (PAGE 634) on
Stop
RPM = 0 or any other shutdown
condition
FUEL SOLENOID (PAGE 602) off,
STOP SOLENOID (PAGE 634) on
Shutdown
Start request READY TO LOAD (PAGE 623) on Running
Stop RPM = 0, Oil pressure not detected,
Generator voltage < 10V, D+ not
active
Ready
If at least one of engine running
indication is detected when Stop
Time (page 219) elapsed.
Stop (Stop
fail)
Note: If all generator parameters are OK and Minimal Stabilization Time (page 216) elapsed, indicates that
GCB is possible to close. In AUTO Mode GCB is closed in this moment automatically.
Note: The start-up sequence can be interrupted in any time by stop request
5.5.2 AMF sequence
State Condition of the transition Action Next state
Mains
operation
Mains failed or MCB FEEDBACK
(PAGE 560) dropout, MCB
Opens On (page 263) = Mains
Fail
MCB CLOSE/OPEN (PAGE 614)off,
Emergency Start Delay (page 255) timer
started
Mains
failure
Mains failed or MCB FEEDBACK
(PAGE 560) dropout, MCB
Opens On (page 263) = Gen
Run
Emergency Start Delay (page 255) timer
started
Mains
failure
Mains
failure
Mains voltage and frequency OK,
MCB Opens On (page 263) =
Mains Fail
After elapsing MCB Close Delay (page
257) MCB CLOSE/OPEN (PAGE 614) on
Mains
operation
Mains voltage and frequency OK,
MCB Opens On (page 263) =
Gen Run
None Mains
operation
Emergency Start Delay (page
255) elapsed, MCB Opens On
(page 263) = Mains Fail
Engine start sequence performed, then
GCB CLOSE/OPEN (PAGE 604) on
Island
operation
Emergency Start Delay (page
255) elapsed, MCB Opens On
(page 263) = Gen Run
Engine start sequence performed, then
MCB CLOSE/OPEN (PAGE 614) off, time
delay Transfer Delay (page 256)
performed and GCB CLOSE/OPEN (PAGE
604) on
Island
operation
