ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
101
Terminal
Event
SMS
Warning
SMS
BOC
SMS
Shutdown
SMS
Event
email
Warning
email
BOC
email
Shutdown
email
CM-RS232-485 no no no no no no no no
CM-Ethernet no no no no yes yes yes yes
CM-GPRS yes yes yes yes yes* yes* yes* yes*
CM-4G-GPS yes yes yes yes yes* yes* yes* yes*
Note: * Only with enabled Internet Connection (page 359).
Alarmlist
Alarmlist is a container of active and inactive alarms. It will appear automatically on the controller display, if a
new alarm occurs, or can be displayed manually from the display menu.
Active alarms are shown as inverted, not yet confirmed alarms are marked with asterisk before them.
Alarmlist contains three types of alarms:
Controller built-in alarms
User configured alarms on binary or analog inputs
ECU alarms
Controller built-in alarms
An alarm message in the alarmlist begins with a prefix, which represents the alarm type (e.g. Wrn, Sd, BOC,
MP, MPR). Then the alarm name follows. In some cases the prefix can be omitted.
User configured alarms
An alarm message in the alarmlist begins with a prefix, which represents the alarm type (e.g. Wrn, Sd, BOC).
Alarm type is selected by user during the configuration of binary or analog input as alarm. Then the alarm name
follows. Name is adjusted by user during the configuration of binary or analog input as alarm.
ECU alarms
The ECU alarms are received from the ECU. The alarms are represented by the Diagnostic Trouble Code,
which contains information about the subsystem where the alarm occurred, the alarm type and the alarm
occurrence counter.
The most common fault codes are translated into text form. Other fault codes are displayed as a numeric code
and the engine fault codes list must be used to determine the reason.
Built-in alarms
Events
specification
Protection
type
Description
Analog Input 1 Wrn WRN
Value measured on analog input 1 is </> than Analog Protection 1
Wrn (page 242) setpoint.
Analog Input 1 Sd SD
Value measured on analog input 1 is </> than Analog Protection 1
Sd (page 242) setpoint.
Analog Input 2 Wrn WRN
Value measured on analog input 2 is </> than Analog Protection 2
Wrn (page 244) setpoint.

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
