Connection Type
Units:
Step:
Range:
1,2,3,4,5
Default value:
4
Generator winding connection.
Setpoint code
Value
Meaning
B04
1
Mono Phase
B04
2
Split Phase
B04
3
3Ph3Wire
B04
4
3Ph4Wire
B04
5
Autodetect
Mono Phase: MONOPHASE,
Single-phase measurement – 1PH
Split Phase: DOUBLE DELTA Connection, Split Phase,
Single-phase measurement – 1PH
3Ph3Wire: DELTA Connection, 3 Phase without neutral - 3 Wires,
Three phase “delta” measurement – 3PD
3Ph4Wire: STAR Connection, 3 phases and neutral - 4 wires,
Three phase “wye” measurement – 3PY
Autodetect:
High-Leg Delta
L1 >=100V; L1 <=140V
L2 >=140V
or
L3 >=100V; L3 <=140V
3Ph4Wire or 3Ph3Wire
L1 >=100V
L2 >=100V
or
L3 >=100V
Split Phase
L1 >=100V
L2 >=100V
or
L3 <= 20V
Mono Phase
L1 >=100V
L2 <= 20V
or
L3 <= 20V
Voltage Autodetect shutdown
NOTE:
The Autodetect option is available only when B06 AMF Function is disabled!
