Table 8: Equipment ID
Item
Description
Site ID
Site ID is the unique equipment identification. It is a hexadecimal string of eight
characters in the range of [00000000~FFFFFFFF]. e.g. 00000000
Site Sub ID
Site Sub ID is used for Master-Slave System. It is the unique identification of each
Master/ Slave Unit and is a hexadecimal string of two characters in the range of
[00~FF].
For the system located with single equipment, the Site Sub ID should be 00.
For Master-Slave system, the Site Sub ID for Master Unit is 00, and the Site Sub
ID for each Slave Unit is represented in the range of [01~FE] in ascending order.
e.g. Master Site ID: 00, Slave Site ID: 01
Figure 39: Site Info
Config:
Enter the required value in setting columns and press [Config] button to finish the configuration operation.
5.5.2 OMC
If the equipment is to be monitored by OMC software over wireless network, users must finish the [OMC.]
in the next step.
The OMC config information requires to be manually entered by users after successful connection to the
equipment.
Figure 40: OMC. Config.
