COMBA mPICO Series - Comm. Config

USER MANUAL FOR mPICO SERIES
ENU Status : 1-0-1
Copyright - refer to title page
Page 60
Figure 75: Site ID
See the table below for configuration details of each parameter.
Table 11: Equipment ID
Item
Description
Site ID
Site ID is the unique equipment identification. It is a hexadecimal string of eight
characters in the range of [00000000~FFFFFFFF]. e.g. 00000000
Site Sub ID
Site Sub ID is used for Master-Slave System. It is the unique identification of each
Master/ Slave Unit and is a hexadecimal string of two characters in the range of
[00~FF].
For the system located with single equipment, the Site Sub ID should be 00.
For Master-Slave system, the Site Sub ID for Master Unit is 00, and the Site Sub
ID for each Slave Unit is represented in the range of [01~FE] in ascending order.
e.g. Master Site ID: 00, Slave Site ID: 01
5.10.2 COMM. CONFIG
If the equipment is to be monitored by OMC software over wireless network, users must finish the
[Comm. Config.] in the next step.
The Comm. Config information requires to be manually entered by users after successful connection to
the equipment.
Figure 76: Com. Config.
