USER MANUAL FOR mPICO SERIES
ENU Status : 1-0-1
Copyright - refer to title page
Page 47
Figure 47: Mode Select
Figure 48: Isolation Detection
Step 3: Click [Next] to enter to Gain Setting Screen shown.
 If select [Auto Setup] mode, the gain setting is automatically done, click next to finish.
 If select [Manual Setup] mode, user can adjust gain by himself, click config to finish setting
