5 Configuration
30 / 80 GB October 2013
3
Tap the <Input x> button of the desired input.
–
The menu "Programmable Inputs and Out-
puts" appears for the desired input.
Programmable Inputs and Outputs
Input 1
Free
External Fault
External Warning
Fault Dryer
Warning Dryer
Fault Condens. Drain
Warn. Condens. Drain
Air Filter
Water Filter
Motor lubrication system
External Speed Limit
Override Timer Start
Pressure Band p2
Enable Sensor B1
Cancel
OK
Fig. 5-19: Menu "Programmable Inputs and Outputs" for
input 1 (e.g. RS)
4 Tap the <Button> for the desired input function.
The <Cancel> button can be used to cancel se-
lection of the input function. The function previ-
ously allocated to the input can be used.
5
Tap the <OK> button.
✓ The input is programmed.
The other free inputs can be programmed in a
similar way.
5.5.2.4 Programmable outputs
The controller has programmable outputs. The
number of outputs may vary depending on the
compressor configuration. See wiring diagram.
NOTE
Programmable outputs may already be occu-
pied by pre-installed accessories and/or optional
equipment. Which outputs are free can be deter-
mined using the supplied wiring diagram.
Outputs can be assigned to
Activating of functions or devices (e.g. warning
lamps in a control centre) if the appropriate out-
put terminals are closed.
NOTICE
Material damage
➯
Max. current / max. voltage per relay output:
1A at 240V.
Service
Warning/Service
Warn./Service/Fault
Ready for Rem. Start
Request for Start
Pressure Band p2
Timer Control
Off
Motor Running
Operating
On-Load
Off-Load
Fault
Warning
Output 1
Programmable Inputs and Outputs
Cancel
OK
Fig. 5-20: Menu "Programmable Inputs and Outputs" for
input 1
Off
The output remains permanently deactivated.
Motor Running
The output is activated if the drive motor is run-
ning.
Operating
The output is activated whenever the compressor
is operating (on-load, off-load or standby).
On-Load
The output is activated if the compressor is on-
load.
Off-Load
The output is activated if the compressor is off-
load.
Fault
The output is activated as long as no fault exists.
The output is deactivated if a fault has arisen.
Warning
The output is activated as long as no warning ex-
ists. The output is deactivated if a warning is trig-
gered.
Maintenance
The output is activated as long as no service is
due. The output is deactivated when a service is
due or overdue. This is triggered within 200 hours
of the next service being due.
Warning/Service
The output is activated as long as no warning ex-
ists or service is due. The output is deactivated
when a warning occurs or a service is due (com-
bined message).
