1-2
Taking a Look at the Computer
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Carey Gregg Saved by: Carey Gregg Saved date: 04/27/00 1:45 PM
Part Number: 170706-002 File name: Ch01
Top Components
Continued
Component Function
4
Num lock light On: Num lock is on and the embedded
numeric keypad is enabled.
5
Caps lock light On: Caps lock is on.
6
Scroll lock light On: Scroll lock is on.
7
Internal microphone Supports audio input when the display is
open or closed.
8
Suspend button** Initiates and exits Suspend.* When pressed
with the
Fn
key, initiates Hibernation.
9
Easy Access Buttons (available on
select models)
Allow direct access to predefined files,
programs, or websites.
:
Windows application key Displays shortcut menu for item beneath
mouse cursor.
;
Battery light On: The battery pack is charging.
Blinking: The battery pack that is the only
available power source has reached a
low-battery condition.
<
Power/suspend light On: Power is turned on.
Off: Power is turned off.
Blinking: Computer is in Suspend.*
NOTE:
The power/suspend light also blinks
if a battery pack that is the only source of
power available to the computer reaches a
critical low-battery condition while
Hibernation is disabled.
=
Right-click button Functions like the right-click button of an
external mouse.
>
Left-click button Functions like the left-click button of an
external mouse.
Used with the TouchPad, drags and
highlights.
?
TouchPad Moves the mouse cursor, selects, and
activates.
@
Microsoft logo key Displays Windows Start menu.
*In Windows 98 the term
Standby
replaces the term
Suspend.
**In Windows 98 the term
sleep button
replaces the term
suspend button.
