2-10 Compaq ProLiant ML370 Maintenance and Service Guide
Small Access Panel
WARNING: To reduce the risk of personal injury from hot surfaces, allow internal system
components to cool before touching them.
To remove the small access panel:
1. Perform the preparation procedures. See “Powering Down the Server” earlier in this
chapter.
2. Open the front bezel (tower model only). See “Front Bezel” earlier in this chapter.
3. Loosen the thumbscrew securing the small access panel to the chassis ➊.
4. Slide the small access panel toward the rear of the unit about 1.5 cm (0.5 inches), then off
to the side
➋.
1
2
Figure 2-5. Removing the small access panel
Reverse steps 1 through 4 to replace the small access panel.
