Removal and Replacement Procedures 2-19
Hot-Plug SCSI Hard Drive
To remove a hot-plug SCSI hard drive:
1. Open the front bezel (tower model only). See “Front Bezel” earlier in this chapter.
2. Press the release button
and swing the lever
outward from the bottom.
3. Pull the hot-plug SCSI hard drive out of the bay
.
1
2
3
Figure 2-15. Removing a hot-plug SCSI hard drive
Reverse steps 1 through 3 to replace the hot-plug SCSI hard drive.
