Removal and Replacement Procedures 2-29
Processor
To remove the processor:
1. Perform the preparation procedures. See “Powering Down the Server” earlier in this
chapter.
2. Open the front bezel (tower model only). See “Front Bezel” earlier in this chapter.
3. Remove the large access panel. See “Large Access Panel” earlier in this chapter.
4. Push in the tabs at each side of the processor until you hear two clicks  .
5. While holding the tabs in, pull out the processor ➋.
2
1
1
1
Figure 2-25. Removing the processor
Reverse steps 1 through 5 to replace the processor.
Use the System Configuration Utility to reconfigure the system if a faulty processor is replaced.
See Chapter 3, “Diagnostics and Troubleshooting,” for more information.
NOTE: Individual heat sinks may vary from the one(s) shown above.
