Diagnostics and Troubleshooting 3-27
100-199, Primary Processor Test Error Codes
The 100 series of diagnostic error codes identifies failures with processor and system board
functions generated by Compaq Server Diagnostics.
Table 3-3
Primary Processor Test Error Codes
Error Code Description Recommended Action
101-xx CPU test failed Replace the processor board and retest.
103-xx DMA page registers test failed
104-xx Interrupt controller master test
failed
105-xx Port 61 error
106-xx Keyboard controller self-test failed
Replace the processor board and retest.
107-xx CMOS RAM test failed
108-xx CMOS interrupt test failed
109-xx CMOS clock load data test failed
1. Replace the battery/clock module and retest.
2. Replace the system board and retest.
110-xx Programmable timer load data test
failed
111-xx Refresh detect test failed
113-xx Protected mode test failed
Replace the processor board and retest.
114-xx Speaker test failed 1. Verify the speaker connection and retest.
2. Replace the speaker and retest.
3. Replace the system board and retest.
116-xx Cache test failed Replace the system board and retest.
122-xx Multiprocessor Dispatch test failed
123-xx Interprocessor Communication
test failed
1. Check the system configuration and retest.
2. Replace the processor board and retest.
3. Replace the system board and retest.
199-xx Installed devices test failed 1. Check the system configuration and retest.
2. Verify cable connections and retest.
3. Check switch and/or jumper settings and retest.
4. Run the Configuration Utility and retest.
5. Replace the processor board and retest.
6. Replace the system board and retest.
