2-26 Compaq ProLiant ML370 Maintenance and Service Guide
I/O Expansion Slot Cover
To remove an I/O expansion slot cover:
1. Perform the preparation procedures. See “Powering Down the Server” earlier in this
chapter.
2. Open the front bezel (tower model only). See “Front Bezel” earlier in this chapter.
3. Remove the small access panel. See “Small Access Panel” earlier in this chapter.
4. Press down on the release button at the top of the I/O expansion slot retention lever  .
5. Swing the I/O expansion slot retention lever upward  .
6. Lift the I/O expansion slot cover up and out of the server  .
1
2
3
Figure 2-22. Removing an I/O expansion slot cover
Reverse steps 1 through 6 to replace an I/O expansion slot cover.
