HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier Revision 6
Serial-Based Remote Product Management MN/HPOD.IOM
5–15
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction
& Qualifier)
Response to Query
Retrieve Alarm
Status
N/
A
117 bytes,
alphanumeric
Query only.
Reports the Alarm status of the unit.
Example:
<1/RAS?’cr’
>0001/RAS=’cr’’lf’
P24VT=OK’cr’
P15VT=OK’cr’
P10V1=OK’cr’
P10V2=OK’cr’
P7V5T=OK’cr’
P5VLT=OK’cr’
N5VLT=OK’cr’
FAN#1=OK’cr’
FAN#2=OK’cr’
HSTMP=OK’cr’
SHTDN=OK’cr’
IICST=OK’cr’
FPOUT=OK’cr’’lf’
Note: BUC=XX, and REF=XX will appear in the list if the BUC, and reference oscillator are installed.
N/
A
RAS?
RAS=x….x
(See Description of
Arguments)
Retrieve
Configuration
Status
N/
A
45 bytes,
alphanumeric
Query only.
Reports the configuration status of the unit.
Example:
<1/RCS?’cr’
>0001/RCS=’cr’’lf’
ATT=12.75’cr’ (Attenuation in dB)
AMP=1’cr’ (RF power amplifier state, 0=OFF, 1=ON)
MUT=1’cr’ (RF mute state, 0=un-muted, 1=muted)
ONL=1’cr’ (Online status for redundancy)
RED=1-1’cr’ (Redundancy state and mode, states: 0=OFF, 1=ON, modes: 0 = auto, 1 = manual)
GOF=00.00’cr’ (Gain Offset in dB)
AFR=1’cr’’lf’ (Auto Fault Recovery, 0=manual, 1=auto)
N/
A
RCS?
RCS=x….x
(See Description of
Arguments)
Redundancy
State
RED= 1 byte,
value of 0, 1, 2
Command or Query.
Set or report as ON or OFF the redundancy state, in the form x, where:
0 = Off
1 = 1:1 Redundancy
2 = 1:2 Redundancy
Example:
<1/RED=1’cr’
>0001/RED=’cr’’lf’
RED=
RED?
RED*
RED?
RED =x
