HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier Revision 6
Serial-Based Remote Product Management MN/HPOD.IOM
5–16
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction
& Qualifier)
Response to Query
Reference
Oscillator
Tuning
REF= 3 bytes,
numeric
Command or Query.
Adjusts the reference oscillator tuning voltage by sending a DAC value in the form xxx, where:
xxx = numeric value from 0 to 255, and the default value is set to 87.
Example:
<1/REF=87’cr’
>0001/REF=
Note: This command sets the DAC value, but the actual Reference Oscillator tuning voltage can be
monitored using the RMS command.
REF=
REF?
REF*
REF?
REF=xxx
(See Description of
Arguments)
Retrieve
Equipment
Type
N/
A
22 bytes,
alphanumeric
Query only.
Returns the Model Number and the version of the MnC firmware installed in the unit.
Example:
<1/RET?’cr’
>0001/RET=CPA-300 VER: 1.0.3’cr’’lf’
N/
A
RET?
RET=x….x
(See Description of
Arguments)
RF Power FET
Current status
N/
A
variable length
depending on
the number of
FETs installed in
the amplifier
Query only.
Returns all the FET currents.
Example:
<1/RFS? ’cr’
>0001/RFS=’cr’
Q01=xx’cr’
Q02=xx’cr’
Q03=xx.x’cr’
Q04=xx.x’cr’
Q05=xx.x’cr’
Q06=xx.x’cr’
Q07=xx.x’cr’
Q08=xx.x’cr’
Q09=xx.x’cr’
Q10=xx.x’cr’
Q11=xx.x’cr’
Q12=xx.x’cr’
Q13=xx.x’cr’
Q14=xx.x’cr’
Q15=xx.x’cr’
Q16=xx.x’cr’’lf’
N/
A
RFS? RFS=x….x
(See Description of
Arguments)
