Comtech EF Data HPOD - Page 97

HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier Revision 6
Serial-Based Remote Product Management MN/HPOD.IOM
5–17
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction
& Qualifier)
Response to Query
Retrieve
Maintenance
Status
N/
A
168 bytes,
alpha- numeric
Query only.
Returns the maintenance status of the unit.
Example:
<1/RMS?’cr’
>0001/RMS=’cr’
P24VT=024.1’cr’
P15VT=015.2’cr’
P10V1=010.4’cr’
P10V2=010.4’cr’
P7V5T=007.8’cr’
P5VLT=005.8’cr’
N5VLT=-05.7’cr’
FANR1=100.0’cr’
FANR2=100.0’cr’
ATEMP=+40.0’cr’
A10V1=010.2’cr’
A10V2=010.2’cr’
FWPWR=+37.6’cr’
RVPWR=02.0’cr’’If’ (optional)
*Note: REFV will appear if REF OSC module is installed.
N/
A
RMS?
RMS=x….x
(See Description of
Arguments)
Serial Number N/
A
9 bytes,
numeric,
000000000 to
999999999
Query only.
Returns the unit’s 9 digit serial number in the form xxxxxxxxx.
Example:
<1/RSN?’cr’
>0001/RSN=072282040’cr’’lf’
N/
A
RSN?
RSN=xxxxxxxxx
(See Description of
Arguments)
Retrieve Utility
Status
N/
A
27 bytes,
alpha- numeric
Query only.
Returns the utility status of the unit.
Example:
RUS=’cr’
ADR=0001’cr’
BDR=9600’cr’
N/
A
RUS?
RUS=x….x
(See Description of
Arguments)
Remote Baud
Rate
SBR= 4 bytes,
alphanumeric
Command or Query.
Set remote baud rate in the form xxxx, where:
9600 = 9600 baud
19K2 = 19200 baud
Example: SBR=9600’cr’
Note: When changing baud rates remotely the response to the command will be returned using the same
baud rate as that used to send the command.
SBR=
SBR?
SBR? SBR=xxxx
(See Description of
Arguments)
