HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier Revision 6
Serial-Based Remote Product Management MN/HPOD.IOM
5–18
Parameter
Type
Command
(Instruction
& Qualifier)
Number of
Arguments
Description of Arguments
Response to
Command
Query
(Instruction
& Qualifier)
Response to Query
Summary Fault
Status
N/
A
1 byte,
value of 0,1
Query only.
Returns the condition of the summary fault relay where:
0 = Not Faulted (SumFLT_COM J6 pin K is connected to SumFLT_NO J6 pin L, and SumFLT_NC J6 pin
M is open)
1 = Faulted (SumFLT_COM J6 pin K is connected to SumFLT_NC J6 pin M, and SumFLT_NO J6 pin L is
open)
Example: <1/SFS?
>0001/SFS=0’cr’’lf’
N/
A
SFS?
SFS=x
(See Description of
Arguments)
Remote
Address
SPA= 4 bytes,
numeric
Command or Query.
Set Physical Address in the form xxxx, where:
xxxx = address between 0001 to 9999, resolution 0001
Example: SPA=0412’cr’
SPA=
SPA?
SPA? SPA=xxxx
(See Description of
Arguments)
Set RTC Time TIM= 6 bytes,
numeric
Command or Query.
Sets or returns the RTC time in the form hhmmss, where:
hh = hours, between 00 and 23;
mm = minutes, between 00 and 59,
ss = seconds, between 00 and 59
Example:(time = 23 hours, 12 minutes and 59 seconds since midnight.):
<1/TIM=231259’cr’
>0001/TIM=’cr’’lf’
TIM =
TIM?
TIM*
TIM?
TIM=xxxxxx
(See Description of
Arguments)
Retrieve
Number of
unread
Stored Alarms
N/
A
2 bytes,
numeric,
00 to 99
Query only.
Returns the number of stored events that remain unread in the alarm log, in the form xx, where:
Xx = A maximum of 99 events may be stored in the alarm log.
Example:
<1/TNA? ’cr’
>0001/TNA=14’cr’’lf’
N/
A
TNA? TNA=xx
(See Description of
Arguments)
Terminal Status
change
N/
A
1 byte,
value of 0,1
Query only.
Indicates if there has been a change in the terminal status since the last time the command was given. A
value of 0 indicates no status change, and a value of 1 indicates there has been a terminal status change.
Example:
<1/TSC?’cr’
>0001/TSC=0’cr’’lf’
N/
A
TSC? TSC=x
(See Description of
Arguments)
Software Image IMG= 1 byte Command or Query.
Current Active software image, in the form x, where:
1=Bulk Image # 1 currently active
2=Bulk Image # 2 currently active
Example: IMG=1 (which is Image #1 active)
IMG=
IMG?
IMG*
IMG#
IMG? IMG=x
(See Description of
Arguments)
