CSC Combination Puller/Cutter UGE048/1103
You can shut down just the cutter portion of the combination
puller/cutter if you need to change or adjust cutter blades:
Press Cut On/Off Softkey to Off to stop cutting
(Softkey text changes to off).
Press Stop Cutter button to disable the servo motor.
Turn Cutter Power On/Off switch to Off. Power
is no longer supplied to the cutter portion of the combina-
tion puller/cutter. The belt puller will continue running.
Follow the procedures Installing Cutter Blades, Section 3.
1
2
3
STOPPING ONLY
THE
CUTTER
M
AKING LARGE
CHANGES TO
THE
PULLER
SPEED
OPERATION 4-37
Turn the potentiometer CW to increase speed
or CCW to decrease speed.
NOTE: For Servo option see separate
Appendix F
1
