System Data Specifications
Power consumption. Depending of system configuration.
Internal system voltage 19–30 VDC
Maximum number of loop units connected to one central 2400
Maximum number of CS-Loop M modules
16
1
Maximum number of loop units connected to a single loop-line 150
Maximum number of CS-Isolators connected to a single loop-line 5
Maximum number of loop units connected to a CS-Isolator 60
Number of loop units to indicate fire with steady light LEDs
Max 10. The first 9 active fire alarms
plus the latest.
Maximum loop cable length per loop
Please refer to section Loop lengths,
page 16
Maximum main loop line cable resistance on the positive side 53 Ω
Maximum main loop line cable capacitance 440 nF
Maximum EX sub-loop loop line cable resistance
26 Ω
2
Maximum EX sub-loop capacitance (explosion group IIC)
77 nF including detectors capacitance
2
Maximum EX sub-loop capacitance (explosion group IIB)
110nF cable capacitance, excluding
detectors capacitance
2,3
Redundant loop capacitance (shielded) 28 nF
Redundant loop capacitance (unshielded) 440 nF
Time to report fire alarms on the backbone interface within 2 seconds
Response time to report a fire alarm.
•
From the moment a detector enters the alarm state, or a manual call
point is activated, to the activation of the common fire relay.
within 3 seconds
Time to recover from a single short circuit on a loop-line.
•
For a single short circuit this means to isolate the short circuit such that
no loop units are lost.
within 120 seconds
Start-up time for the safety function after cold start (external power on) 60 seconds
Time to enter fault condition after a fault has occurred within 100 seconds
Accumulated probability of dangerous failure on demand of the safety
function (PFDavg)
Less than 0.01
NOTE!
A warning will be displayed on the menu screen until the logic solver in the system
is up and running, which is the first minute after the system has been powered up.
Hint!
For detailed requirements regarding system modules and loop units, refer to the data
sheets.
1) Max 10 CS-Loop M modules can be installed in a FDS using the CS-Safety M module and maximized loops (150 units).
2) See "EX Calculator", revision 4 or later
3) In the case of explosion group IIB you may ignore the detector's internal capacitance
