2 Fault codes who register short circuit are:

•
138 LOOP SHORT CIRCUIT.
Reported from loop units.
•
139 LOOP A SHORT CIRCUIT.
Reported from CS-Loop M.
•
140 LOOP B SHORT CIRCUIT.
Reported from CS-Loop M.
Secondary fault codes can also appear
and give assistance in trouble
shooting. Refer to cause and remedy
in section Fault codes, page 65.
3 The combination of fault codes indicates that the short circuit is located between the
reported loop unit on the A side and the reported loop unit on the B side.
8.5.6 Muting faults
1 Simultaneously mute all the faults by pressing the Mute key.
2 The fault alarm light stops flashing and changes
to a steady yellow light.
The fault is put in a fault list under
Menu » 1 Fault Alarms » 1 Fault List.
8.5.7 Reset faults
NOTE!
The cause of the problem must be corrected before a fault can be reset.
The faults are reset from the Fault list under Menu » 1 Fault Alarms » 1 Fault List.
•
Select the fault and confirm by pressing the reset key.
The fault is reset
1 The fault is reset and it disappears from the fault list.
The fault is not reset
1 The fault is not reset and the reason for this is displayed.
2 Check and correct the problem. See the Fault code list in the manual
for more information.
3 Attempt to reset the fault by pressing the reset key.
8.5.8 Save the System Log to a USB Memory Stick
If you want to check the information saved in the system log you can download it
from the central unit. The system log files contain information generated for
evaluating the system, such as lists of system components, system software and key
events.
