Consilium CFD5000 T/CM2.2 - Testing of System Parts (Control Panel CM2.2); Prerequisites for Testing

8Commissioning Installation & Commissioning Manual
48
5100607_CFD5000 T - CM2.2_Installation & Commissioning Manual_T_EN_2023_F
2 Press and hold both arrow keys + for 5 seconds to open the Enter Access Code
menu.
3 Use the arrow keys to scroll and select the digits for the Access Code.
Confirm with the Local Mute key (= Next digit or Enter).
(Key = Previous.)
4 Proceed to choose address (according to parameters defined for the system) and layout
for the Repeater module:
1. Enter Central Address
2. Enter Module Address
3. Enter Layout (Marine or Transport)
For all menu alternatives use the arrow keys to scroll and select. Confirm with the Local
Mute key.
Follow the instructions on the lower part of the screen.
5 Reboot (power off/on) the Repeater module (it can take the module up to one minute to
restart).
Layout and functions:
•
Marine
Layout “marine” gives the repeater no operational privileges except for local
mute of the buzzer and to view fire alarms, fault alarms and disablements.
•
Transport
Layout “transport” gives the repeater control privileges. When the Fire or Fault
list is displayed, the “Local mute” key acts as mute and reset for the
selected/marked alarm or fault.
CAUTION!
This layout shall not be used if the Repeater is located in a
public area!
8.4 Testing of System Parts (Control Panel
CM2.2)
8.4.1 Prerequisites for testing
CAUTION!
A fault alarm concerning a wrong loop unit address has to be dealt with promptly. A
correct address is essential to communicate alarms from the loop unit to the central
unit.
CAUTION!
A loop unit with fault indication of a broken input or output has to be replaced as
soon as possible in order to secure the functionality of the complete fire detection
system.
