Coretec BS Series - 4 Construction; Name of each Part of the Controller

BS Controller for AC SERVO PRESS
Instruction Manual Ver1.08
BS-M3A-1B
- 16 -
4.
Construction
4.1.
Name of each part of the controller
OK/NG LED
ID SW
Extended bus(Anybus)
CN4 RS-232C CH1
CN5 RS-232C CH2
CN6,7 RS-485
CN9 Ethernet
CN10 PI/O
Control
Power LED
CN10 Control power
CN11 Backup battery
CN34
Emergency stop
CN33 MR-J3A Parallel
CN32 Origin sensor
CN31 Load cell
Status LED
Code LED
