Alarm code table
An alarm code cannot be known only with a controller. Please use BS
Configurator or the below-mentioned option article.
Basic alarm code
Alarm
code
Name
Meaning/correspondence
001
The abnormalities
in RAM backup
Abnormalities were discovered by the data of the backup
domain of SRAM.
The domain containing abnormalities
is shown by the detailed alarm code.
Consumption of a
backup battery or t
he omission of the connector of a
backup battery is suspected(CN11)
. When a backup file
exists, restoration can restore easily.
(Refer BS_Configurator handling description 7-6-2
backup)
002
The abnormalities
in CAL
The output is over tolerance level at the time of the
calibration of a load cell. Please check calibration value
by manual operation. (Refer BS
Configurator handling
description 4-3 proofreading) When a tool
has been
crashed
, calibration value may be out of order. In this
case, repair is required.
003
The abnormalities
in ZERO
The no-load output value of a load cell is over tolerance
level. Please check a load cell output b
y the monitor
function. (Refer BS Configurator handling description 4-3
proofreading) When a tool has been crashed, no-load
output value may be out of order. In this case, repair is
required. Moreover, it may become abnormalities in
ZERO if a program is started when load is applied to a
tool. In this case, please start a program after removing
the cause of load.
006
Program
un-registering.
The specified user program does not exist in a controller.
Please check that an appointed program number is in a
controller.
007
Tool
un-registering.
A tool type has not been registered. Please set a suitable
tool type as a controller. Consumption of a backup battery
or t
he omission of the connector of a backup battery is
suspected(CN11). All itmes of thr setup menu in BS
Configurator need to be set up. When a backup file exists,
restoration can restore easily.
(Refer BS Configurator handling description 7-6-2
backup)
008
Origin error
Abnormalities occurred during origin and origin was not
completed. The following th
ings can be considered as a
factor which bars origin,
STOP signal is inputted,
Excessive load exists. Please remove these causes and
perform origin operation again.
009
The abnormalities
in SG amplifier
The communication with a tool is unusual. Please check
the connection of an encoder cable(CN31).
010
The abnormalities
The type
ｓ
of the tool connected with the tool type set as
