BS Controller for AC SERVO PRESS
Instruction Manual Ver1.08
BS-M3A-1B
- 55 -
in a tool type
the controller differ. Please set the right tool type to the
controller.
011
The abnormalities
in EEPROM
Abnormalities were discovered at the contents of
EEPROM. Please check the numerical value of each item
on the maintenance information screen of BS
Configurator. Please consult with a operating window,
when there is an unusual numerical value.
013
Basic parameter
or gain parameter
un-registering.
The parameter which accompanies a tool has not been
registered. All itmes of thr setup menu in BS
Configurator need to be set up. When a backup file exists,
restoration can restore easily.
(Refer BS Configurator handling description 7-6-2
backup)
014
The abnormalities
in the contents of
Program
The parameter exceeding rating is contained in the
program under execution. Please check the contents of a
user program. When each table is being referred to with
speed, the position, and the load parameter, please check
the contents of each table.
016
The abnormalities
in a driver
It is the alarm about a motor driver. Please refer to a
detailed alarm code.
017
AC power supply
is OFF state.
AC power supply is in off state. Please check the state of
power supply.
018
The abnormalities
in origin
A program was started in the state of un-completing an
origin.
019
The abnormalities
in a data
collection failure
Access for data collection was not made from PC during
user program execution. The abnormalities of data
collection PC and Ethernet cable are suspected. When
you do not perform data collection,
please set this
function off.
020
Emergency stop
STOP signal of a general-purpose input operated. Please
turn off STOP signal and perform reset operation.
021
Tool type
mismatching
error
The tool type of the performed program differs from the
tool type set to the controller.
022
Power supply
re-injection
demand
Since the backup file was restored, a power supply needs
to be re-supplied.
023
Backup area
partial error
The checksum error occurred in a part of backup domain.
024
The abnormalities
in JOG operation
signal
When JOG_ENA is turned on, JOG+ or JOG- has already
turned on.
025
It was started in
AC power supply
OF F.
It was going to work the controller in spite of OFF state
of AC power supply.
026
Since it is
JOG_ENA ON
, it
cannot start.
It was going to start the program in spite of the state of
ON of JOG_ENA.
027
Under operation
of JOG or origin
It was going to start the program during JOG operation
or origin.
029
Anybus
It failed in initialization of the card which was equipped
