BS Controller for AC SERVO PRESS
Instruction Manual Ver1.08
BS-M3A-1B
- 9 -
impedance in the final equipment shall satisfy the overcurrent characteristics of the
breaker so that the breaker shall be interrupted within 0.4s or less when earth fault is
occurred.)
This symbol assumes that there is a potential for
personal death or injury if this expression is ignored
and this product is mishandled.
When attaching the CPS body, allow a space of 25 mm or more for the right and left
directions and 80 mm or more for up and down directions for cooling.
Do not apply more load on the Servo press tool than allowed.
The life might be considerably shortened.
For connection to the protective earthing terminal, one wire should
be provided for each
terminal.
The insulation’s color of the protective earthing conductor shall be green-and-yellow.
Design the sequencer circuit under consideration of safety measure such as emergency stop.
Make sure to observe for sequencer circuit
Safety measure
This symbol assumes that there is a potential for
personal death or injury if this expression is ignored
and this product is mishandled.
Insert or pull off the connector only after turning off the power.
Otherwise, controller might fail.
Improper understanding of stroke might cause serious accident. Please understand the
Section 8 in this manual to handle.
The EMC directive applies not to the servo units alone but to servo-incorporated
machines and equipment.
This requires the EMC filters to be used with the servo-incorporated machines and
equipment to comply with the EMC directive.
Please ask a concrete solution to our office.
This equipment is classified into the partly completed equipment according to
Machinery Directive (2006/42/EC). Therefore, after this equipment is incorporated into
the final machinery, conformity with Machinery Directive (2006/42/EC) shall be needed
in the final machinery.
