BS Controller for AC SERVO PRESS
Instruction Manual Ver1.08
BS-M3A-1B
- 32 -
O READY_RUN
I START
I PRG.NO
O RUN
O ANS
O OK/NG
I RESET
7
7
5
5
4
4
8
8
7.4.
JOG
When you turns on JOG_ENA, it is required for PNO1/JOG+, and PNO2/JOG-
to be in the state of off. It will become alarm if JOG_ENA is turned ON when
either of those signals is ON.
7.5.
Program execution
I SERVO_ON
I
JOG_ENA
I PNO1/JOG+
I PNO2/JOG-
I JOG_SPD1/U_IN0
I JOG_SPD2/U_IN1
O
IN_JOG/AREA
