Coretec BS Series - Post Judge

BS Controller for AC SERVO PRESS
Instruction Manual Ver1.08
BS-M3A-1B
- 35 -
7.8.
Post Judge
"Post Judge" is the function to take in waveform data to PC, to perform special
analysis in PC, and to return a judgment to BS controller. This function can
perform judgment processing which cannot be realized only by the real-time
operation within BS controller. Please refer to a BS_Configurator handling
description for details.
PLC
CPS
PC
PLC
BS
PC
A post judg
number is set up
vis AnyBus I/f.
Start each
spindles
The status sense to each
spindles.
A numerical and waveform
data are collected from the
ended spindles.
When using Post Judge,
waveform analysis is
performed according to the
specified judgment number.
A result is returned to BS.
O.K./NG is outputted
considering the
judgment from PC,
and an internal
judgment.
