BS Controller for AC SERVO PRESS
Instruction Manual Ver1.08
BS-M3A-1B
- 19 -
AC Power *
11
AC200V
3φ
PLC
DC Power *11
DC24V
Emergency Stop *12
Servo Amp.
MR-J3-700A
BS Controller *3
BS
-
M3
A-
1
B
BS200 Tool
Sequence cable
CCKSQ-3M *4
Parallel I
/F cable
*
2
CBSPIF-
**M
Serial Com. cable *2
CBS422-**M
Origin Sensor cable *1
CBSGS-
**M
Load Cell cable *
1
*14
CBSLC-**M
Encoder cable *1 *8
MR
-J3
ENSCBL**M-L
Motor cable *1 *7
CBSMT
10-**
M
Brake cable
CBSBK
-
**M
*1
*
12
LAN cable(cross) *5
CCKLANC-5M
RS-
232
C cable
CCK232
-
3M
*10
FA Network
Board
Application
Software
Regen.Reg. *13
MR-RB31
MR-RB51
PC
LED Display
LDS-24
LED Display cable
CCKDSP-**M *6
Load Cell *9
Fig.4-3-2 BS200 Series
*1 The length of a cable is selectable from 5,10 and 20m. The junction cable is not
prepared.
*2 The length of a cable is selectable from 0.5 and 1m.
*3 The connectors in a dashed line are included to the controller set.
*4 This is unnecessary when using a FA Network Board.
*5 The type of LAN cable may not be crossing when using a HUB.
*6 The length of a LED Display cable is selectable from 5 and 10m.
*7 The model name of movable cable is CBSMT20R-**M.
*8 The model name of movable cable is MR-J3ENSCBL**M-H.
*9 The load cell is an option.
*10 Detail of the model name is different for each PLC type.
*11 A customer prepares cables.
*12 A customer controls this line.
*13 A external regeneration resister is an option.
*14 A model without a load cell needs a load cell cable to recognize a tool type.
To Next Page
