BS Controller for AC SERVO PRESS
Instruction Manual Ver1.08
BS-M3A-1B
- 25 -
Output
Bit
number
Signal name
Contents
0
ALARM(N.C)
Alarm. It is normal
ｙ
closing. It turns off in the
state of alarm.
1
ALM_MR(N.C)
The alarm state of MR-J3A is shown. It is normal
ｙ
closing.
2
READY
The completion of operation preparation.
3
IN_ORIGIN/BAT.ALARM
In origin mode/Battery alarm are superposed.
BAT.ALARM is chosen when JOG_ENA is ON.
4
RUN
It turns on during program execution.
5
OK
O.K. judging output. The output timing of
O.K./NG is a time of executing jdg command in a
program.
6
NG
NG judging output.
7
IN_JOG/AREA1
Under JOG operation/Area signal1 are
superposed. IN_JOG is chosen when JOG_ENA is
ON.
8
P_ANS1/U_OUT0
The response of the bit 0 of binary value which
specifies an execution program number/User
output 0 are superposed. User outputs are chosen
when USER_SEL is ON. It is the same to the bit
12.
9
P_ANS2/U_OUT1
The response of the bit 0 of binary value which
specifies an execution program number/User
output 1 are superposed.
10
P_ANS4/U_OUT2
The response of the bit 1 of binary value which
specifies an execution program number/User
output 2 are superposed.
11
P_ANS8/U_OUT3
The response of the bit 2 of binary value which
specifies an execution program number/User
output 3 are superposed.
12
P_ANS16/U_OUT4
The response of the bit 3 of binary value which
specifies an execution program number/User
output 4 are superposed.
13
U_OUT5
User output 5.
14
U_OUT6
User output 6.
15
USER_SEL_ANS
The response of USER_SEL.
16
BAT.ALARM
It is an output only for battery alarms. *1
17
ORIGIN_END
It turns on, when origin is completed. It turns off,
when origin is required. *1
18
PJ_WAIT
When using a post judgment, it turns on in the
state of waiting a judgement from a PC.
19
AREA2
Area signal 2.
20
AREA3
Area signal 3.
21
AREA4
Area signal 4.
22-31
RESERVED
* Above bit16 can be used only when Anybus option is chosen. It is that PI/O (CN9)
