30 3 - Maintenance instructions
COROB
TM
D300
3.9.2 Installing a canister
NOTE!: If there is no stirring motor in the new canister, remove the stirring motor from the old
one and attach it to the new one.
Procedure
1. Remove the hose from the old canister and fasten it to the new one.
2. Place the canister over the rack for canisters and lower it in position.
3. Fasten the hose into the pump:
- Push the hose into pump’s suction side.
- Place the special tool between the tap and it’s sleeve and push the sleeve outwards from
the valve.
Figure 64: Place the tool between the pump and
the sleeve and push away from the pump.
Figure 65: Disconnect the stirring motor’s wire.
Figure 66: Pull up the canister and the hose.
