Crestron Electronics CP4N - Mount the Antenna

94 • 4-Series™ Control Systems Product Manual — Doc. 8559B
Observe the following when connecting the control system:
l
Use Crestron power supplies for Crestron equipment.
l
The control system is powered over PoE (Power over Ethernet)via a Crestron PoEinjector
(PWE-4803RU) or a Crestron PoEswitch (CEN-SW-POE-5 or CEN-SWPOE-16). All
PoEequipment is sold separately.
l
The included cables may not be extended.
l
Mount the included antenna per the guidelines described in Mount the Antenna (below).
l
Connect the chassis ground lug to a known earth ground circuit (such as building steel) to
ensure that the control system is grounded properly.
l
Apply power after all connections have been made.
Mount the Antenna
The included antenna should be placed in a location that maximizes signal strength and limits
impedance. Refer to the Best Practices for Installation and Setup of Crestron RFProducts.
