RMC4 Installation
Use the following procedures to install the RMC4.
Mount the Control System
The control system can be mounted onto a flat surface or a standard DIN rail using the included
mounting bracket.
CAUTION:To prevent overheating, do not operate the control system in an area that
exceeds the environmental temperature range (32 to 104°F or 0to40°C) for this device.
Optional rack mount and pole mount kits (not included)are also available for use with the RMC4.
For more information, refer to the RMK-IFE-1U Installation Guide and the PLMK-IFE-101
Installation Guide.
Surface Mounting
1. Detach the control system from the mounting bracket by pulling the left and right flanges
of the bracket outward to release the tabs that hold the control system in place.
2. Attach the mounting bracket to the surface by using four appropriate mounting screws
(not included) through the four mounting holes on the bottom of the bracket.
3. Align the slots on the bottom of the control system with the tabs on the mounting
bracket.
4. Press the control system into the bracket until it snaps into place.
5. (Optional) Secure the control system to the bracket using the two included 6-32x3/8in.
screws as shown in the following illustration.
