Product Manual — Doc. 8559B 4-Series™ Control Systems • 39
COMPUTER
(front)
(1)USBType-B connector, female;
USB2.0 computer console port;
For setup only
Controls and Indicators
PWR (1) Bicolor green/amber LED, indicates operating power is present;
Amber indicates that the device is booting and is not yet ready to operate;
Green indicates that the device is ready to operate
NET (1) Amber LED, indicates communication with Cresnet devices
MSG (1) Red LED, indicates control processor has generated a logging message
HW-R (1) Recessed push button, initiates a hardware reset
SW-R (1) Recessed push button, initiates a software reset
CNPSFAULT (1)Red LED and (1) push button;
LEDindicates an excessive Cresnet load is detected at the NETport;
Push button resets the fault indication
SLOT1–3 (3)Green LEDs, indicates control cards are present in the corresponding rear
panel slots
LAN (rear) (1) Bicolor green/amber and (1) amber LEDs;
Green/amber LEDindicates Ethernet link status and connection speed;
Amber LEDindicates Ethernet activity
CONTROL
SUBNET(rear)
(1) Bicolor green/amber and (1) amber LEDs;
Green/amber LEDindicates Ethernet link status and connection speed;
Amber LEDindicates Ethernet activity
Power
Main Power 2.4A@100–240VAC, 50/60Hz
Power over Ethernet
Plus (PoE+)
IEEE 802.3at compliant PoE+ PSE (Power Sourcing Equipment);
120W total power;
Each CONTROL SUBNET port supplies up to 30 W to power one PoE+ (Class 4)
PD (Powered Device)
Available Cresnet Power 75W (3.125A@24VDC)
Environmental
Temperature 41 to 104°F (5 to 40°C)
Humidity 10% to 90% RH (noncondensing)
Heat Dissipation 43BTU/hr
Enclosure
Chassis Metal, aluminum, black finish, vented sides and top
Faceplate Extruded metal, black finish, polycarbonate label overlay
Mounting Freestanding or 2 RU 19-in. rack mountable (adhesive feet and rack ears
included)
Dimensions
