Cygnus DIVE Technical Specifications
Measurement Range Measurement Ranges in Steel
Multiple Echo mode;
S2C probe
S3C probe
S5C/A probes
3 to 250 mm
2 to 150 mm
1 to 50 mm
[0.120 in. to 10.00 in.]
[0.080 in. to 6.000 in.]
[0.040 in. to 2.000 in.]
Single Echo mode;
T5B probe
T2C probe
2.0 to 100 mm
3.0 to 150 mm
[0.080 in. to 4.000 in.]
[0.120 in. to 6.000 in.]
Echo-Echo mode;
T5B probe
T2C probe
4.0 to 50 mm
6.0 to 50 mm
[0.160 in. to 2.000 in.]
[0.240 in. to 2.000 in.]
Accuracy ±0.1 mm (±0.004”) or 0.1% of thickness measurement
whichever is the greatest.
Resolution 0.1 mm (0.005”) Low Resolution Mode or
measurement >99.95 mm
0.05 mm (0.002”) High Resolution Mode and
measurement <100.0 mm
0.01 mm (0.001”) Single Echo Mode only and
measurement <100.0 mm
0.05 mm (0.002”) High Resolution Mode and
measurement <100.0 mm
0.01 mm (0.0005”) Single Echo Mode only and
measurement <100.0 mm
Display
Type of Display Colour AMOLED Display
Display Size QVGA 320 x 240 Pixels 2.8”
Display Information Thickness Value and A-Scan Display
Transmitter
Shape of Pulse Square
Pulse Energy : Voltage (peak-
to-peak)
70 V p-p
Pulse Energy : Rise Time 3 ns (max)
Pulse Energy : Pulse Duration S2C : 220 ns
S3C : 100 ns
S5A / S5C : 67ns
T2C : 220 ns
T5B : 100 ns
Receiver
Gain Control Automatic Gain Control up to pre-set Maximum Gain value
120 dB dynamic range.
Frequency Range 1.0 MHz to 10.0 MHz (-6dB)
Other Information
