Cygnus DIVE Operating Manual
M2-DIVE-M-ENG_Iss5.docx
Page 81 of 118
Connection D
iagram
Connector
Details and
Signals
See Connection s
from page 114
Using CygL
ink with
Helmet
View
As HelmetView and CygL
ink both need to conn
e
ct to the spa
r
e
connector on the
gauge a “Y” sp
litter cable is requ
ired. For th
e
part number see Accessor
ies on page 103.
DIVE Gauge
Umbilical Cable
1 twisted pair + screen
(500m maximum length)
USB-RS485
Converter
Computer with
CygLink
80
82
