Page 76 of 118
umbilical cable with connectors fitted, or the customer can make
their own umbilical cable using connectors supplied with cable
tails.
Operation
Turning the Unit On
To turn on the TSR simply press the key with the Red Triangle, the
Cygnus Logo screen will then be displayed. If not connected to a
DIVE gauge the display shows “NO CONNECTION”.
This is normal – it just means no data is being received yet.
Turning the Unit Off
To turn the unit off press the key with the Red Triangle.
Changing the Displayed Units
To change the displayed measurement units between metric (mm)
and imperial (inch) press the left MENU key, the UNITS setting will
be highlighted, then press the middle EDIT key to change the
units.
Display Hold Function
Whist measuring, the middle key HOLD can be used to freeze the
display and hold the current thickness measurement. Press the
middle key again to release the HOLD function.
Automatic Display Backlight
The display backlight automatically turns off in bright light
conditions, it will automatically turn on when the ambient light
level drops.
Connecting to the DIVE Gauge
