Cygnus DIVE Operating Manual
M2-DIVE-M-ENG_Iss5.docx
Page 85 of 118
Connecting the
Gauge to CygL
ink for the First
Time
1.
Turn on the gauge
2.
Run CygLink V5
3.
From the Menu c
lick;
Connect
└
Discover new
Gauge and Con
nect
4.
CygLink will search a
ll the
available Com ports li
stening for
a Cygnus gauge.
.
If a gauge is detecte
d then it will
connect and sav
e these settings
for next time.
5.
When connected
you should see d
etails of the gau
ge in
the status bar at
the bottom and ‘
Connected’
6.
If the connection is ever
lost the sta
tus bar will show
‘Lost
Connection’
84
